Yamaha AG06MKII USB Mixer & Audio Interface - White

  • Sale
  • Regular price R 5,760.00
Shipping calculated at checkout.


Your Audience Awaits.

Two heads are better than one. The same can be said for microphone inputs, especially when it comes to live streaming. The AG06MK2 offers the same user-friendly configuration and operation that has become synonymous with the AG series, but also comes equipped with two phantom-powered mic inputs for condenser microphones. Combined with flexible connectivity, including an upgraded 4-pole mini I/O, the AG06MK2 opens a broader range of dialogue, interview, musical ensemble performance, or other streaming applications that the AG01 or AG03MK2 setups can’t cover.

Expand your Streaming Capabilities

The AG06MK2 allows you to connect two condenser microphones of your choice, as well as two stereo line inputs for instruments, and an upgraded 4-pole mini jack (TRRS) for smartphone input/output capability. Of course, it’s also possible to add audio from devices connected via USB in LOOPBACK mode as with previous AG models. This diverse range of connectivity makes it possible to use high-sensitivity microphones, along with each of the audio sources, for a variety of streaming applications such as podcasts with dialogue, interviews, vocal performances with an acoustic instrument, or even a live band.



Features at a Glance:

  • Two condenser microphones can be used simultaneously
  • +48 V phantom power on CH1-2 input for condenser mics or Dl boxes
  • Hi-Z input for guitars on CH2
  • High resolution (24-bit, 192 kHz) 2-track audio recording and playback
  • 4-pole mini input/output (TRRS) to support a wider range of streaming applications
  • Flexible inputs and LOOPBACK function ideal for live streaming or recording
  • Mute button for convenient live streaming
  • Easy control and pro sound with 1-TOUCH effects (COMP/EQ, REVERB and Amp Simulator)
  • AG Controller (Windows/Mac/iOS ) for precise parameter control
  • Windows/Mac support by USB-C connection
  • iOS connectivity via Apple camera adaptor (requires external USB power supply)
  • Android supported by 4-pole mini input/output (TRRS)
  • USB-C power input (5 V DC, 900 mA)
  • Cubase Al, WaveLab Cast, Cubasis LE and Rec'n'Share are available



 Specifications:

Mono[MIC/LINE]

2 - CH1: Combo (Mic, +48 V phantom power / Line)
3.5 mm (1/8") stereo mini (Headset mic, Plug-in power)
CH2: Combo (Mic, +48 V phantom power / Guitar input / Line)
*CH1 input and Headset mic cannot be used simultaneously

Stereo[LINE]

2 - L/R Stereo: Phone, RCA

Smartphone

1 - PHONES / HEADSET PHONES *Cannot be used simultaneously

USB

1

PHONES

2 - PHONES / HEADSET PHONES *Cannot be used simultaneously

Smartphone

1 - 4-pole mini input/output (TRRS)

MONITOR OUT

1

STEREO OUT

1

USB

1

Bus

1 Stereo

Functions

MUTE button x 1, PAD button x 2, HI-Z button x 1,
STREAMING OUT (DRY CH 1-2G / INPUT MIX / LOOPBACK), MIX MINUS MIC (ON / OFF)

DSP

COMP/EQ, REVERB (SPX Reverb), AMP SIM *Detail is operated on AG Controller

USB Audio

2 IN / 2 OUT, USB Audio Class 2.0 Compliant, Sampling Frequency: Max. 192 kHz, Bit Depth: 24-bit, Type-C

USB DC Power input

1 - Type-C, 5 V DC, 900 mA

Power requirements

5 V DC, 900 mA

Power consumption

Max. 4.5 W

Dimensions

W: 152 mm
H: 63 mm
D: 201 mm

Included Accessories

USB 2.0 Cable (1.5 m), Quick Guide, Safety Guide,

Wavelab Cast Download Information, Cubase AI Download Information

Operating Temperature

0 to + 40 ℃
