SPECS
- neck type
- GRXMaple neck
- top/back/body
- Quilted Maple Art Grain topPoplar body
- fretboard
- Jatoba fretboardWhite dot inlay
- fret
- Medium frets
- number of frets
- 22
- bridge
- T106 bridge
- string space
- 10.5mm
- neck pickup
- Infinity R (H) neck pickupPassive/Ceramic
- middle pickup
- Infinity RS (S) middle pickupPassive/Ceramic
- bridge pickup
- Infinity R (H) bridge pickupPassive/Ceramic
- factory tuning
- 1E,2B,3G,4D,5A,6E
- string gauge
- .009/.011/.016/.024/.032/.042
- hardware color
- Chrome
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 42mm at NUT
- b : Width
- 57mm at 22F
- c : Thickness
- 19.5mm at 1F
- d : Thickness
- 21.5mm at 12F
- Radius :
- 305mmR
Features
Maple neck
The Maple neck provides stability and bright tonal character.
Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
-
